Model No: GT08 series
Unionwell GT08 White Translucent Mechanical Keyboard Switch
Model Number:GT08
Max. Current:10mA
Max. Voltage:12V
LED:NO
Interface Type:USB
Rating:12VDC/AC max.10ma AC/DC max
Initial Contact Resistance:200mΩ Max
Insulation Resistance:100MΩ Min
Voltage Resistance: AC 100V (50-60Hz) 1minute
Electrical life:over 10,000,000 cycles (Load )
Mechanical life:over 10,000,000 cycles (No Load )
Ambient Humidity:≤85%RH
Operating Temperature Range:-40℃~+80℃
Hand Solding Condition:3Sec Max at 360℃±10℃
Max. Current:10mA
Max. Voltage:12V
LED:NO
Interface Type:USB
Rating:12VDC/AC max.10ma AC/DC max
Initial Contact Resistance:200mΩ Max
Insulation Resistance:100MΩ Min
Voltage Resistance: AC 100V (50-60Hz) 1minute
Electrical life:over 10,000,000 cycles (Load )
Mechanical life:over 10,000,000 cycles (No Load )
Ambient Humidity:≤85%RH
Operating Temperature Range:-40℃~+80℃
Hand Solding Condition:3Sec Max at 360℃±10℃
minimum order :
1 piece
Quantity :
Product Description
The Unionwell GT08 White Translucent Mechanical Keyboard Switch is a mechanical keyboard switch specifically developed for the slim and lightweight design of laptop keyboards and the demands of high-frequency input. Its stable actuation force and clear feedback ensure a smooth and precise typing experience even during extended periods of typing.
As a laptop keyboard switch, the GT08 series maintains sensitive actuation within a wide temperature range of -40℃ to +80℃, making it suitable for business use, mobile applications, and high-intensity daily typing scenarios. With a mechanical lifespan exceeding 10 million keystrokes and an electrical lifespan of 20 million keystrokes, it ensures reliable durability over long-term use.
As a high-performance keyboard switch meticulously designed by a micro switch manufacturer, it operates stably under rated conditions of 10mA 12DC/AC, providing a more comfortable and durable typing experience for modern laptops.
Feature
◆ Selectable with tactile sound or smooth silent operation
◆ Smooth and natural touch response, no sticking during button presses
◆ Lifespan over 10 million clicks
◆ Can be equipped with RGB-LEDs for vibrant backlighting
◆ Patented product, world's first
◆ Smooth and natural touch response, no sticking during button presses
◆ Lifespan over 10 million clicks
◆ Can be equipped with RGB-LEDs for vibrant backlighting
◆ Patented product, world's first
Parameter
| Electrical Characteristics | Rated Load | 12V DC/AC Max. 10mA AC/DC max. |
| Initial Contact Resistance | 200mΩ Max. | |
| Insulation Resistance | 100MΩ Min. | |
| Withstand Voltage | AC 100V(50-60Hz) 1 Minute | |
| Electrical Lifespan | Over 20,000,000 cycles(Load) | |
| Bounce Time | Operating speed<400mm/s 5msec | |
| Characteristics | Tactile Force | 70±15gf |
| Tactile Travel | 0.65±0.2mm | |
| Operating Travel | (TP±0.05) ≤OP≤1.2mm | |
| Total Travel | 1.6±0.3mm | |
| Resting Force | RF=20gf Min. | |
| Mechanical Life | Over 10,000,000 cycles(without load) | |
| Operating Temperature | -40℃~+80℃ | |
| Operating Humidity | ≤85%RH | |
| Manual Soldering Conditions | 3Sec Max.360℃±10℃ |
Drawing
Application
As a mechanical keyboard switch optimized for thin and light devices, this product is suitable for high-frequency input scenarios on laptop keyboards. Its transparent white casing not only facilitates even backlight transmission but also makes the overall structure more refined and compact.
In laptop applications, this switch provides clear key feedback and a stable actuation point, maintaining a consistent feel even during long typing sessions or intensive office work. Its mechanical life exceeds 10 million keystrokes, demonstrating exceptional durability and high reliability.
